Industrial Grapple Rake

  • Bolted tines operated independently or together like clamshell
  • One of the heaviest, toughest grapples ever built
  • High Tensile 80,000 plate steel, 1,479–1,495 lbs. operating weight
  • 1.50” thick bottom tines and 0.75” thick top tines
  • Reinforced to give incredible strength and durability
  • 41” opening gives ability to grab huge loads of brush
  • Unique clam-style allows for efficient back raking
  • XL replaceable excavator style teeth for aggressive digging
  • 0% financing available - no interest if paid in full within 12 months.

72”/84” Models | 15.5” Depth | 36” Height | 8 Tines | 41” Grapple Opening | 2.5” Cylinder

Skid Pro’s skid steer grapple rake is engineered for maximum strength and versatility in tough landscaping and clearing tasks. With its robust construction, featuring 1.5-inch thick bottom tines and a 41-inch jaw opening, this attachment excels at handling heavy loads like brush, logs, and rocks. Our design allows operators to utilize back raking with the top grapple, providing optimal reach and functionality for efficient material handling. The reinforced frame, replaceable teeth, and industrial cylinders ensure durability and long-lasting performance in demanding conditions. Whether for digging, grubbing, or raking, this grapple rake is built for high productivity and minimal effort.

Specifications

MODEL 72″ 84”
Bucket Depth 15.5″ 15.5”
Bucket Height 36″ 36”
Number of Tines 8 8
Average Tine Spacing 10.5″ 12”
Tine Thickness (Top) 0.75″ 0.75″
Tine Thickness (Bottom) 1.5″ 1.5″
Grapple Jaw Opening 41″ 41”
Cylinder Bore 2.5″ 2.5”
Cylinder Rod 1.5″ 1.5”
Approximate Weight 1,479 lbs. 1,495 lbs.

Features



Industrial Design

  • Industry leading 1 ½” thick bottom tines, and ¾” top tines for maximum strength
  • Robust back plate & heavily gusseted lower grapple frame give unreal strength. No HP limit on this grapple!
  • Top, middle brush guard and back protected cylinders and hose routing for optimal durability in extreme work environments
  • Oversized, hardened pins with greaseable pivot points for added longevity and easy maintenance
  • Industrial cylinders for max clamping force and durability, all with protected hose routing
  • Engineered for use on the industry’s biggest machines in the most extreme work conditions and for ultra long life
  • Gloss black powder coat paint for better adhering and longer lasting finish



Operator Ease

  • Back raking allows for higher productivity and less manual labor cleaning up small material
  • Shorter bottom tines are perfect for digging, grubbing, ripping and sifting of heavy loads
  • Aggressive tread safety step
